Русский| Connector Type | |
|---|---|
| Contact Material | Gold/Silver plating |
| Contact Type | Male |
| Fastening Type | |
| Termination | Solder |
| Mounting Type | Panel Mount |
| Insulating Materials | |
| Insulation Impedance | ≥5000MΩ |
| Mechanical and Working Life | 500 Cycles |
| Number of Positions | |
| Operating Temperature | -60 ℃ ～ +105 ℃ |
| Orientation | |
| Shell Material | Aluminum Alloy |
| Shell Size | 12 |
| Vibration | 1-5000Hz 20g |
| Contact Dia. | 6 contacts Ø 0.6 mm 2 contacts Ø 2.0 mm |
| Operating Current | 0.5/10.0A |
| Operating Voltage | 150V |
| Contact Resistance | ≤5MΩ |
