| M8-10C-1L-NPN-PW | M8 Distribution Box 10-Port Single Channel NPN M12 Pre-Made Interface |
| M8-10C-1L-PNP-PW | M8 Distribution Box 10-Port Single Channel PNP M12 Pre-Made Interface |
| M8-10C-2L-NPN-PW | M8 Distribution Box 10-Port Dual Channel NPN M12Pre-Made Interface |
| M8-10C-2L-PNP-PW | M8 Distribution Box 10-Port Dual Channel PNP M12 Pre-Made Interface |
These distribution boxes typically consist of a metal or plastic enclosure with multiple M8 ports. The number of ports can vary depending on the specific application requirements. Each port is designed to accommodate an M8 connector, which can be used to connect various devices such as sensors, actuators, switches, or other equipment.
M8 distribution boxes provide a centralized and organized solution for connecting multiple devices in an industrial environment. They help simplify wiring and reduce installation time by providing a single point of connection for multiple devices. Additionally, these distribution boxes often feature a compact and rugged design, making them suitable for use in harsh environments with high levels of vibration, moisture, or temperature variations.
Accessories Type
Connector Interface
PCB Interface
PCB Interface with Junction Box
Cableded
M8 distribution boxes 10-Port, M12 Pre-Made Interface
M8 Distribution Boxes Shell Size
Field Connection M12 Plug Connector
M8 Pin Definition:
| M8 Single Channel | M8 Dual Channel | ||
| PIN 1: | + | PIN 1: | + |
| PIN 2: | / | PIN 2: | S2 |
| PIN 3: | - | PIN 3: | - |
| PIN 4: | S1 | PIN 4: | S1 |
Wiring Diagram
Single Channel PNP
Dual Channel PNP
Application
Commonly used in industrial automation, robotics, sensor networks, and fieldbus systems, M-Series distribution boxes feature multiple connector receptacles for connecting sensors, actuators, controllers, and other devices. In addition, the M-Series distribution boxes are water, dust and corrosion resistant, making them suitable for use in harsh environmental conditions.
